Description
ZOTAC Gaming Alloy mATX Cabinet Black
The ZOTAC GAMING ALLOY mATX Computer Case is ZOTAC’s first ever computer case that is designed with the DIY enthusiast in mind. With a solid airflow design and the potential for up to 10 fans to be installed, an mATX form factor that fits most flagship GPUs, quick detachable panels for easy maintainance and more, the ALLOY case effortlessly adds a touch of elegance and performance to any gaming station.
Key Features:
- Elegant Design: Appearance tailored for ZOTAC GAMING’s latest flagship GPUs
- Effortless Assembly: Quick-detachable panels, toolless PCIe screw design, Push-to-detach dust filter
- Three 120mm PWM Fans included, supports up to 10 Fans or up to one 360mm liquid-cooling Radiator
- Airflow optimized with dedicated air-guide ramp for GPU cooling
- Wide Compatibility, up to 412mm GPU clearance
| General Specifications | |
| Form Factor | mATX |
| Color | Black |
| Materials | Steel, Aluminum, ABS, Tempered Glass |
| Side Panel | Tempered Glass |
| Access & Controls | Power, USB 3.2 Gen1 (5Gbps, Type-A), USB 3.2 Gen2 (10Gbps, Type-C), Headphone/Mic Combo Jack |
| Dimensions | 458 x 222 x 433 mm |
| Compatibility & Clearances | |
| Motherboard Compatibility | mini ITX, micro ATX |
| Max. PSU Length | ≤180mm (ATX Form Factor) |
| Max. CPU Cooler Height | ≤170mm |
| Max. GPU Length | ≤412mm |
| Radiator | Top: 120/140/240/280/360mm Rear: 120mm |
| PCIe Slots/Drive Bays | |
| PCIe Slots | 5 |
| 3.5″ | 1 |
| 2.5″ | 1 |
| Cooling | |
| Front | 3 x 120mm (2 x 120mm pre-installed) |
| Top | 3 x 120mm / 2 x 140mm |
| Midplate | 2 x 120mm |
| PSU Shroud | 1 x 120mm |
| Rear | 1 x 120mm (pre-installed) |
| Dust Filter | Front, Bottom |
| Additional Features | |
| Fan Specifications | |
| Fan Type | PWM |
| Fan Speed | 1350 ~ 1450 RPM |
| Cable Length | 550mm |
| Lighting | N/A |
| Miscellaneous | |
| Accessories | Accessories Kit, Quick Start Guide |
| Warranty | 2 Years |
| Note** | **Prices, Specifications & Features are subject to change without notice |
